DVY23
BenQ
DVY23 Technical Specifications
Camera
& Lens
|
Feature |
Specification |
|
Sensor Type |
1/2.8" CMOS, 2.07
Megapixel |
|
Video Resolution |
1080p, 720p, SD @ 30/60 fps |
|
Optical Zoom |
20x |
|
Digital Zoom |
10x |
|
Field of View |
Horizontal: 55° | Vertical: 31°
| Diagonal: 63° |
|
Focus |
Auto and Manual |
|
Low Light Sensitivity |
0.5 Lux |
|
Lens Type |
High-quality Glass |
PTZ
Performance
|
Feature |
Specification |
|
Pan Range |
±170° |
|
Tilt Range |
-30° to +90° |
|
Pan Speed |
0.1° to 100°/sec |
|
Tilt Speed |
0.1° to 45°/sec |
|
Preset Positions |
10 via Remote Control | 255 via
LAN |
|
Image Flip |
Built-in Gravity Sensor
(Auto-adjusts image based on orientation) |
Connectivity
& Audio
|
Feature |
Specification |
|
Video Outputs |
USB 3.0, HDMI, 3G-SDI, Ethernet
(RJ-45) |
|
Audio Input |
1 x 3.5 mm TRS Stereo Line
Input |
|
Streaming Protocols |
RTSP, RTMP (Supports YouTube
and Facebook Live) |
|
Control Interfaces |
RS232, RS422, RS485, LAN, IR
Remote |
|
Power |
DC 12V / PoE (Power over
Ethernet) |
Physical
& Compatibility
|
Feature |
Specification |
|
Dimensions (H x W x D) |
150 mm × 181 mm × 116 mm |
|
Weight |
1.38 kg (3.04 lbs) |
|
Operating Systems |
Windows 7/8.1/10, macOS 10.10+,
Linux (UVC), Chrome OS |
|
Certifications |
Zoom, Microsoft Teams, Google
Meet compatibility |
-
SKU:
-
Brand: BenQ
-
Category: PTZ Conference Camera
